ECX-1310 GTX1050

產品特色

    • 可彈性支援8核心Intel® Xeon®/Core™ i7/i5/i3 (Coffee Lake) 處理器和工作站等級Intel® C246晶片組
    • 雙通道DDR4 SO-DIMM記憶體,最高可支援64GB
    • NVIDIA® GeForce® GTX 1050獨立顯示核心,先進的NVIDIA Pascal™ GPU架構,最高可支援8K解析度
    • 多重VGA, DVI, HDMI和Displayport顯示介面,最多可支援6個獨立顯示輸出
    • 6個USB 3.1介面,其中4個第2代USB 3.1,可支援10Gbps超高速資料傳輸
    • 2個獨立GigE LAN、4個COM RS-232/422/485
    • 4個2.5吋硬碟抽取槽,可支援軟體RAID 0, 1, 5, 10
    • 儲存介面 : 1個M.2插槽、1個CFast卡插槽、4個SATA III
    • 擴充介面 : 1個PCIe插槽、2個Mini PCIe/mSATA插槽、1個M.2插槽
    • 3個SIM卡插槽,支援WiFi/4G/3G/LTE/GPRS/UMTS
    • 支援12V至36V寬範圍DC電流輸入,80V突波防護
    • 具電源延缓開關機設定 (車載模式)



產品簡介

    8核心第9代/第8代Intel® Xeon®/Core™ i7/i5/i3 (Coffee Lake Refresh/Coffee Lake),工作站等級Intel® C246 晶片組,NVIDIA® GeForce® GTX 1050獨立顯示核心,先進的NVIDIA Pascal™架構,最高支持8K解析度、6個獨立顯示輸出,多個GigE LAN支援PoE+,超高速第2代USB 3.1介面 (10Gbps)、外部SIM插槽支援WiFi、4G、3G、LTE、GPRS、UMTS等網路環境,PCI/PCIe擴充介面支援額外獨立顯卡及PoE卡,12V至36V寬電壓輸入並具80V突波保護、支援遠端電源切換功能和特殊開關機電源模式切換功能 (Ignition Power Control),提供系統在惡劣環境中運作必備的穩定性,超恩ECX-1400/1300 GTX1050系列多顯示核心嵌入式系統,是您建置虛擬實境、自動駕駛系統、機器人控制、智慧醫療、智能監控或其他AIoT相關應用的可擴充選擇。




產品規格

System
Processor 8 Cores Intel® Xeon®/Core™ i7/i5/i3 Processor (CFL-R S)
Chipset Intel® C246
BIOS AMI
SIO IT8786E
Memory 2 DDR4 2666MHz SO-DIMM, up to 64GB (ECC/Non-ECC)
I/O Interface
Serial  4 COM RS-232/422/485 (ESD 8KV)
USB
- 6 USB 3.1 (External)
- 1 USB 2.0 (Internal)
GPIO 16 GPIO
LED Power, HDD, Wireless
SIM Card  3 external SIM sockets
Expansion
Mini PCIe 2 Full-size for PCIe/USB/external SIM/mSATA
PCI/PCIe 1 PCIe slot
M.2 1 M.2 Key E socket
Graphics
Graphics Processor
- Intel® UHD Graphics 630
- NVIDIA® GeForce® GTX 1050
Interface
- 1 VGA : Up to 1920 x 1200 @60Hz
- 1 HDMI : Up to 4096 x 2304 @60Hz
- 2 DVI : Up to 1920 x 1200 @60Hz
- 1 DisplayPort : Up to 7680 x 3840 @60H
- 2 DisplayPort : Up to 4096 x 2304 @60Hz
Storage
SATA 4 SATA III (6Gbps) support S/W RAID 0, 1, 5, 10
mSATA 2 SATA III (Mini PCIe type, 6Gbps)
M.2 1 M.2 Key B socket
Storage Device
- 1 CFast socket, Push-in/Push-out ejector
- 4 front-access 2.5" SSD/HDD trays
Audio
Audio Codec Realtek ALC892, 5.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
Ethernet
LAN 1 Intel® I219LM GigE LAN supports iAMT 12.0
LAN 2 Intel® I210 GigE LAN
Power
Power Input 12V to 36V, DC-in
Power Interface 3-pin Terminal Block : V+, V-, Frame Ground
Ignition Control 16 mode (Internal)
Remote Switch 3-pin Terminal Block
Surge Protection Up to 80V/1ms Transient Power
Others
TPM Optional Infineon SLB9665 supports TPM 2.0, LPC interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control when CPU overheats.
Software Support
OS Windows 10, Linux
Mechanical
Dimension  260mm x 215mm x 104.1mm (10.24" x 8.46" x 4.10")
Weight 5.8 kg (12.79 lb)
Mounting
- Wallmount by mounting bracket
- DIN Rail mount (optional)
Environment
Operating Temperature
35W TDP CPU : -20°C to 60°C (-4°F to 140°F)
65W TDP CPU : -20°C to 55°C (-4°F to 131°F)
80W TDP CPU : -20°C to 45°C (-4°F to 113°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% Humidity, non-condensing
Relative Humidity 95% at 60°C
Shock
- IEC 60068-2-27
- SSD : 50G @ wallmount, Half-sine, 11ms
Vibration
- IEC 60068-2-64
- SSD : 5Grms, 5Hz to 500Hz, 3 Axis
EMC CE, FCC, EN50155, EN50121-3-2
